SoundTube
SoundTube HP890i-BK 8" 2-Way Hanging Speaker, Black
HP890I-BK | 9W-HP890IBK
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Patented BroadBeam Ring waveguide technology delivers a consistent dispersion pattern for maximum intelligibility and edge-to-edge coverage. One 8" treated fiber woofer and one 1.42" compression driver (1.0" exit) mounted to a proprietary cast-aluminum baffle and heat sink. High output and 120W transformer for the sound reinforcement and PA markets. Patented ZeroReflection enclosure technology for optimal sound reproduction and cabinet rigidity. Easy-access five-position selectable tap switch for 25-, 70.7- and 100V applications with transformer bypass position. Includes hanging hardware with galvanized steel cables and integrated SpeedClamp self-locking wire grip for fast, easy and secure installation. Also includes Euroblock connector and terminal weather boot. Average sensitivity of 94.0 dB offers high output capabilities and reduced amplification costs. UL 1480 (UEAY) and 2239 (hanging cable) approved.
Main Features
- Patented BroadBeamHP waveguide technology delivers a consistent dispersion pattern for maximum intelligibility and edge-to-edge coverage (2-8 kHz,independently verified)
- One 8" (203mm) treated fiber woofer and one 1.42" (36mm) compression driver (1" exit) mounted to a proprietary cast-aluminum baffle and heat sink
- Weatherized components for indoor/outdoor applications
- High output (115 dB) and 120W transformer for the sound reinforcement and PA markets
- Patented ZeroReflection enclosure technology for optimal sound reproduction and cabinet rigidity
- Easy-access,five-position selectable tap switch for 25, 70.7, and 100V applications with transformer bypass position
- Includes hanging hardware with galvanized steel cables and integrated SpeedClamp self-locking wire grip for fast,easy and secure installation. Also includes Euroblock connector and terminal weather boot
- Average sensitivity of 94 dB offers high output capabilities and reduced amplification costs
- UL 1480A and UL 2239 (hanging cable) approved
- High quality black or white paint finish. Custom paint colors optional
General Information
Name: SoundTube HP890i-BK 8" 2-Way Hanging Speaker, Black
Category: SoundTube, Pro AV, Commercial Audio, Pro Speakers
UPC Code:
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number 9W-HP890IBK Brand Name SoundTube Manufacturer Part Number HP890I-BK
Maximum Frequency Response 22 kHz Minimum Frequency Response 65 Hz|93 Hz
Color Black Height 17.23" Width 14.82"
Power Source 4 Pin 5.08mm Euroblock
Mount Type Baffle
Environmental Certification CE, RoHS, UL Environmentally Friendly Yes
