Product Overview
125 kHz reader for indoor & outdoor installations. Mullion and single gang mounts included (2N1).
Description
The NBT125-W supports all Linear 125 kHz cards & fobs, and supports most cards & fobs made by HID, AWID and Farpointe (HAF).
NBT125-W outputs reader-to-controller data in Wiegand format, making it compatible with a vast majority of existing access control panels.
2-N-1: Includes single-gang and mullion mounting hardware in the box.
IP67 rated for indoor and outdoor installations.
Main Features
- Frequency: 125 kHz (contactless prox)
- Mounting: A single reader for metal door and windows frames, single-gang wall boxes, and flat surfaces.
- Dimensions (Mullion): 1.48" W x 4.74" H x 0.54" D (37.5 mm x 120 mm x 13.7 mm)
- Dimensions (Single-gang): 2.99" W x 4.74" H x 0.54" D (76.2 mm x 120 mm x 13.7 mm)
- Certifications: FCC, ICC, CE, UL Standard 2942, IP67
- Read Range: Up to 3 inches (76 mm)
- Cabling: 24 AWG minimum, multiconductor, stranded, with an overall foil shield
- Supported Data Output: Wiegand
- Operating Temperature: -40° F to 149° F (-40° C to +65° C)
- Audio Tone Beeper: Included standard
General Information
Name: Linear NBT125-W 125 kHz Indoor/Outdoor Proximity Reader, Includes 2-N-1 Single Gang and Mullion Mounting Hardware
Category: Linear, Access Control, Keypads & Readers, Proximity Readers
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number LN-82501257K Brand Name Linear Manufacturer Part Number LN-82501257K Product Model NBT125-W Product Name NBT125-W Access Reader
Indoor/Outdoor Indoor, Outdoor
