Product Overview
Vigitron's OmniiCopper Vi27004 4-port Ethernet and PoE Receiver brings new performance standards to the growing need for high-speed transmission of full bandwidth Ethernet and PoE power over extended distances of Single-Pair Wires. It operates in conjunction with Vi27000 transmitter over virtually any 2 conductor wires reliably. The Vi27004's unique transmission technology eliminates the potential for cross-talk resulting in the perfect solution for bundled cable runs used in many elevators and building communication systems. Its PoE performance conforms to IEEE 802.3af/at standards.PoE power can Pass-Through from a PoE source to eliminate the need for a local power supply at the camera location and increase system reliability.The Vi27004 is a 4-port receiver. Up to four Vi27004s can be placed within Vigitron's Vi5000R rackmount tray to create a 4, 8, 12, or 16-port rack-mount receiver solution. The Vi27004 can pass through up to 36W PoE power on each port compliant to IEEE802.3.at to power the connected IP camera. It is type-tested under NEMA-TS2 environmental standards for extended temperature operation between -30°C to +50°C. The Vi27000 series is the perfect solution for extended-distance data and power transmission for elevators, warehouses, parking lots, campuses, casinos, and many more. OmniiCopper Vi27000 series is MegaPixel Certified (MPC), the type tested to network packet performance standards, and major camera brand compatibility tested to assure you error-free and reliable operations. Installation cost savings, tested and proven design and performance go into making the Vi27000 series the perfect solution for building CCTV wiring.
Main Features
- Receives Data, Video and PoE Power up to 3,000 feet (914 m) over Single-Pair Wires
- Provides 4 ports compatible with UTP, STP, and untwisted pairs
- Provides Network speeds up to 100Mbps
- Compact design for easy installation in tight spaces
- Requires no switch setting or network programming
- Mega-Pixel Certified (MPC) High data rate, ideal for high bandwidth requirements of Mega-pixel cameras and multiple IP cameras systems
- Type tested to RFC-2544 TCP/IP network bandwidth packet transmission standards
- Type tested for -30°C to +50°C temperature range under conforming to NEMA-TS2 testing standards
- Up to 4 units can be installed in a Vi5000R rackmount unit to make a sixteen port model
General Information
Name: Vigitron VI27004 4-Port Ethernet / PoE Receiverer Over Single-Pair Wires
Category: Vigitron, Data Comm & Networking, PoE Devices, PoE Extenders
UPC Code: 841144101884
Country of Origin: China. Country of origin is subject to change.
Specifications
ADI Part Number VG-VI27004 Brand Name Vigitron Manufacturer Part Number VI27004 Product Series Vi27000
Network (RJ-45) Yes Number of Network (RJ-45) Ports 4
Environmental Certification CE, FCC Part 15, Subpart B, Class B 2010, RoHS, WEEE
